Inyector Multi-modo OPTIC-4

OPTIC-4 Multimode GC Inlet

Brand

OPTIC-4 is a highly advanced Gas Chromatograph multi mode inlet system with sophisticated
temperature and gas flow control that can be used for the most demanding Gas Chromatograph analyses.
can be used for hot injections, cold injections, large volume, on-column injections, in liner derivatization,
thermal desorption, pyrolysis and more.
The patented* design of the injector body helps to have the best transfer of the compounds from the inlet onto
the analytical column. This can be seen both for volatile and non-volatile compounds.
OPTIC-4 Multi Mode Inlet can cool very fast because of the low thermal mass. The GC inlet system can work from
cryogenic temperatures (-150°C) up to very high temperatures (600°C) with a ramp rate up till 60°C/sec.
Depending on solvent type, liner type and injection speed it is possible to inject from 0.1µl till 500µl in the OPTIC inlet.
With the optional inlet peltier cooler it is possible to cool faster and reach initial temperatures of +7°C.

More info

Downloads

OPTIC-4

Choose your product

Filters Clear Filters

Reference GL-2406-3001

Description OPTIC-4S GC Injection System
