NiGen HF-1

Brand

PSA molecular sieve technology dedicated to offer UHP Nitrogen for GC and ICP
CLAIND "Fast Purity“ patent which allows the high-purity nitrogen delivery within 30 minutes
Built-in compressor with two 50 l. internal tanks,one for compressed air and the other for nitrogen
Highly reliable Air compressor with maintenance required only after 14,000 hours of work
2 gas outlets : available: UHP Nitrogen and Oil Free Air
CPU with Touch Screen Display connectable with CAN-BUS to the generators
(up to 32 units) which allows the monitoring of operational status.
Equipped with full turn wheels for easy moving

Specifications

Downloads

FLOW RATE	6 Nl/min ± 10% a 2000 m asl
TECHNOLOGIES EMPLOY	PSA CLAIND
OUTPUT PRESSURE	0 - 7 bar/0 - 100 psi ± 3%
PURITY	> 99,9995 %
OIL FREE COMPRESSOR	Included
ELECTRICAL SUPPLY	115 Vac ±10% 60 Hz 200 W 230 Vac ±10% 50 Hz 200 W
INDEX OF PROTECTION	IP20
NOISE	< 50 dBA during the stand by of the compressor < 65 dBA with compressor running
OPERATING TEMPERATURE	5°C fino 35°C (41°F fino 95°F)
ENVIRONMENTAL HUMIDITY	max 90% without condensation
DIMENSIONS	Height: 132 cm/52” Width: 44 cm/17.3” Depth: 110 cm/43.3”
WEIGHT	220 kg/489 lbs
PNEUMATIC CONNECTIONS	Compressed air inlet: G 1/4” female Nitrogen outlet: G 1/4” female
